Steel Formwork System Roll Forming Machine
Steel formwork is mainly used in construction. In the past, steel formwork was mainly welded with steel plates, and the higher-end ones were made of aluminum materials.
Description
Roll Forming Machine for Steel Formwork System
Steel formwork is mainly used in construction. In the past, steel formwork was mainly welded with steel plates, and the higher-end ones were made of aluminum materials. Whether it is manual welding or using high-end aluminum materials, the production efficiency is slow and the price is high. Now we use roll forming machine to produce steel formwork, which improves production efficiency.
Nowadays, roll forming machines can produce more and more products and provide production efficiency in many industries. Beenew Machinery has nearly 30 years of experience in roll forming machine production. As long as you provide product drawings, we can customize the roll forming machine you need. Welcome to contact us.
Parameter
| Material Type | Seel strip |
| Thickness（mm） | 0.8-1.5 |
| Yield stress（Mpa） | 235-350 |
| Max. Forming speed（m/min） | 25m/min |
| Roller material | 45# steel with hard chrome treatment |
| Roller driven type | Chain transmission |
| Controller | PLC |
| Operation | Touch screen and button |
| Hydraulic system pressure（Mpa） | 12 |
| Hydraulic station motor power（KW） | 7.5 |
| Main motor power（KW） | 15 |
| Total weight（Kg） | About 95000 |
